Modern Design Bentonite Geosynthetic Clay Liner for Waterproof Storage and Isolation
  • name
  • name
  • name
  • name
  • name
  • name

Modern Design Bentonite Geosynthetic Clay Liner for Waterproof Storage and Isolation

MOQ: 1000 square meters
Price: $1.95/square meters >=1000 square meters
Standard Packaging: waterproof film
Supply Capacity: 20000 Square Meter/Square Meters per Day
Detail Information
Product Description
Detail Information
Place of Origin
Shandong, China
Brand Name
TAIAN HONGYUAN
Model Number
GCL-3
Warranty:
Lifetime
After-sale Service:
Online Technical Support, Onsite Installation, Onsite Training, Onsite Inspection, Free Spare Parts, Return And Replacement
Project Solution Capability:
Graphic Design, 3D Model Design, Total Solution For Projects, Cross Categories Consolidation
Application:
Villa
Design Style:
Modern
Type:
4000G-6500G
Product Name:
Geosynthetic Clay Liner
Material:
Bentonite
Keyword:
Sodium Bentonite Geosynthetic Clay Liner
Color:
Black White
Function:
Waterproof Storage Drainage Isolation
Usage:
Waterproof Projects
Advantage:
Easy Set
Height:
38mm 48mm 68mm
Length:
30m/50m
Feature:
High Compressive Strength
Port:
QINGDAO
Minimum Order Quantity:
1000 square meters
Price:
$1.95/square meters >=1000 square meters
Packaging Details:
waterproof film
Supply Ability:
20000 Square Meter/Square Meters per Day
Product Description
Products Description

GCL

As a new type of environmentally friendly and ecological composite anti-seepage material, Bentonite Waterproof Blanket has been widely used in civil engineering such as water conservancy, environmental protection, transportation, railway, civil aviation and other civil engineering with its unique anti-leakage performance. Foundation treatment and capping of waste landfills, seepage prevention of artificial lakes, reservoirs, channels, rivers, roof gardens, seepage prevention of famous underground structures such as basements, subways, tunnels, and underground passages, etc.
Modern Design Bentonite Geosynthetic Clay Liner for Waterproof Storage and Isolation 0
Modern Design Bentonite Geosynthetic Clay Liner for Waterproof Storage and Isolation 1
Modern Design Bentonite Geosynthetic Clay Liner for Waterproof Storage and Isolation 2
Product Paramenters
Modern Design Bentonite Geosynthetic Clay Liner for Waterproof Storage and Isolation 3
Items
Technical index
GCL-NP
GCL-OF
GCL-AH
Mass area ratio (g/m2)
≥4000
≥4000
≥4000
Swelling coefficient of Bentonite(ml/2g)
≥24
≥24
≥24
Ethylene blue adsorbed(g/100g)
≥30
≥30
≥30
Tensile strength(N/100mm)
≥600
≥650
≥600
Elongation at maximum load (%)
≥10
≥10
≥8
Peel strength (N/100mm)
≥40
≥40
≥40
Filtration (ml)
≤18
≤18
≤18
Durability of Bentonite (ml/2g)
≥20
≥20
≥20
Modern Design Bentonite Geosynthetic Clay Liner for Waterproof Storage and Isolation 4
Product features
1. Has excellent waterproof and anti-seepage performance. 2. Bentonite is a natural inorganic material, it will not undergo aging reaction and has good durability. 3. It will not cause any adverse impact on the environment. It is an environmentally friendly material. 4. The construction is simple and not limited by the temperature of the construction environment. 5. The performance-price ratio is relatively high, and the use is very extensive.
Modern Design Bentonite Geosynthetic Clay Liner for Waterproof Storage and Isolation 5
Modern Design Bentonite Geosynthetic Clay Liner for Waterproof Storage and Isolation 6

ADVANCED PRODUCTION LINES

The company has the most advanced production equipment, with a complete production process, can produce 20000m2 GCL per day, product quality compliance with international standards.
Modern Design Bentonite Geosynthetic Clay Liner for Waterproof Storage and Isolation 7

Construction drawing of Sri Lanka Water Park
Modern Design Bentonite Geosynthetic Clay Liner for Waterproof Storage and Isolation 8

Construction drawing of the artificial lake
Modern Design Bentonite Geosynthetic Clay Liner for Waterproof Storage and Isolation 9

Landfill construction drawing
Product packaging
Modern Design Bentonite Geosynthetic Clay Liner for Waterproof Storage and Isolation 10
Modern Design Bentonite Geosynthetic Clay Liner for Waterproof Storage and Isolation 11
Modern Design Bentonite Geosynthetic Clay Liner for Waterproof Storage and Isolation 12
Modern Design Bentonite Geosynthetic Clay Liner for Waterproof Storage and Isolation 13
Modern Design Bentonite Geosynthetic Clay Liner for Waterproof Storage and Isolation 14
Modern Design Bentonite Geosynthetic Clay Liner for Waterproof Storage and Isolation 15
Modern Design Bentonite Geosynthetic Clay Liner for Waterproof Storage and Isolation 16
FAQ

1. who are we?
We are based in Shandong, China, start from 2010,sell to Domestic Market(50.00%),South America(30.00%),Southeast Asia(10.00%),Mid
East(10.00%). There are total about 11-50 people in our office.

2. how can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;

3.what can you buy from us?
bentonite mat,swellable mat,geocell,geomembrane,geotextile

4. why should you buy from us not from other suppliers?
Hongyuan International Co., Ltd is one industrial and trading enterprise, with the production intelligence of geomembrane,
geotextile, GCL(Geosynthetic clay liners) and geotechnical materials. Our products have been exported to many countries, and are

5. what services can we provide?
Accepted Delivery Terms: FOB,CFR,CIF,EXW,Express Delivery；
Accepted Payment Currency:USD,EUR,JPY,CAD,AUD,HKD,GBP,CNY,CHF;
Accepted Payment Type: T/T,L/C,D/P D/A,MoneyGram,PayPal,Western Union,Cash,Escrow;
Language Spoken:English,Chinese,Spanish
